Repair set parts list
Pos. Designation Version Piece
FK(X)40/ ...
390 470 560 655 755
1)
2000 Set valve plate N, TK 2 80240 80240 80241 80241 -
2010 Set shaft seal with mineral oil charge N, K, TK 1 80682 80682 80682 80682 80682
2010 Set shaft seal with ester oil charge N, K, TK 1 80023 80023 80023 80023 80023
2020 Set oil pump N, K, TK 1 80017 80017 80017 80017 80017
2030 Set piston Ø 50 optimized N, K 4 80102 - - - -
2030 Set piston Ø 55 optimized N, K
4 - 80103 - - -
2030 Set piston Ø 60 optimized N, K
4 - - 80104 - -
2030 Set piston Ø 65 optimized N, K
4 - - - 80105 -
2030 Set piston Ø 70 optimized
K 4 - - - - 81283
2035 Set piston Ø 50 rilled, optimized
TK 4 80220 - - - -
2035 Set piston Ø 55 rilled, optimized
TK 4 - 80107 - - -
2035 Set piston Ø 60 rilled, optimized
TK 4 - - 80210 - -
2035 Set piston Ø 65 rilled, optimized
TK 4 - - - 80225 -
2040 Set piston connecting rod with 2 rings Ø 50 N, K
4 80108 -
- - -
2040 Set piston connecting rod with 2 rings Ø 55 N, K
4 - 80109 - - -
2040 Set piston connecting rod with 2 rings Ø 60 N, K
4 - - 80110 - -
2040 Set piston connecting rod with 2 rings Ø 65 N, K
4 - - - 80111 -
2040 Set piston connecting rod with 2 rings Ø 70
K 4 - - - - 81296
2045 Set piston con. rod Ø 50 rilled, optimized
TK 4 80249 - - - -
2045 Set piston con. rod Ø 55 rilled, optimized
TK 4 - 80250 - - -
2045 Set piston con. rod Ø 60 rilled, optimized
TK 4 - - 80251 - -
2045 Set piston con. rod Ø 65 rilled, optimized
TK 4 - - - 80226 -
2050 Set crankshaft 49 stroke, optimized N, K, TK
1 80154 80154 80154 80154 80154
2060 Set shut-off valve NW25 (AL) N, K, TK
1 08084 - - - -
2060 Set shut-off valve NW32 (AL) N, K, TK
1 - 08082 08082 08082 08082
2)
2070 Set shut-off valve NW20 (AL) N, K, TK
1 08100 - - - -
2070 Set shut-off valve NW25 (AL) N, K, TK
1 - 08084 08084 - -
2070 Set shut-off valve NW32 (AL) N, K, TK
1 - - - 08082 08082
2)
2080 Set sight glass Ø 18 up to type code 012 N, K, TK
2 08698 08698 08698 08698 -
2080 Set sight glass Ø 22 from type code 013 N, K, TK
2 08552 08552 08552 08552 08552
2090 Set gaskets (not shown)
N, TK 1 80230 80230 80230 80230 -
2090 Set gaskets (not shown)
K 1 80001 80001 80001 80001 81298
2100 Set connecting rod N, K
4 08449 08449 81293 81293 81293
2100 Set connecting rod
TK 4 81085 81085 81085 81085 -
2110
Set clamping ring with oil felt
up to type code 014
N, K, TK
1 80129 80129 80129 80129 -
2120 Set oil drain hose
N, K, TK 1 81424 81424 81424 81424 81424
2130 Set oil lter N, K, TK
1 80076 80076 80076 80076 80076
2140 Set front bearing ange N, K, TK
1 80081 80081 80081 80081 80081
2150 Set cylinder roller bearing N, K, TK
2 80118 80118 80118 80118 80118
2900 Set valve plate
K 2 80010 80010 80010 80010 81297
13 I Parts list
