6
09665-08.2018-Gb
15
16
17
1
2
3
5
6
8
9
10
4
11
12
13
14
18
7
3 I Product description
Main and functional parts
1. Discharge shut-off valve
2. Cylinder cover
3. Valve plate
4. Compressor housing
5. Location hole for tting magnetic coupling
6. Integrated leak oil collector
7. Leak oil drain hose
8. Shaft seal
9. Shaft end
10. Baseplate
11. Connection thermal protection thermostat
12. Oil lling plug
13. Oil sight glasses (2x)
14. Oil drain plug
15. Suction line valve
16. Oil pump
17. Oil drain plug / Oil lter
18. Name plate
