Compressor size Most operated cylinders
4 cylinder compressor 1
6 cylinder compressor 3 or 4
8 cylinder compressor 5 and 6
10 cylinder compressor 5, 7 and 8
3.4.4 Package components
Checklist package components
Description/checkpoint
1 Drive guard
2 Coupling alignment
3 Oil level float switch on compressor and oil separator
4 Pressure safety switches
5 Pressure gauges
6 Thermostats and thermometers
7 Electrical control system
8 Oil return protection and oil return system
9
Electric motor and thermistors
(Consult motor manufacturer)
10 Base frame, vibration dampers and bolts
11 Piping
12 Oil cooler (oil side and air side) and fan
13 Thermo-Master
