Geberit ACO 103PLUS - Pressing with Geberit pressing attachments; Prerequisite

EN
ATTENTION
Damage to the device due to incorrect
rechargeable battery
▶ Make sure that only suitable Geberit
lithium-ion batteries of type
Milwaukee12V
are used.
5 Insert the rechargeable battery into
the pressing tool from the rear.
Result
✓ Pressing tool is in idle state. No LED is
lit.
Pressing with Geberit
pressing attachments
WARNING
Risk of injury caused by flying
fragments
▶ Wear protective goggles and a
protective helmet.
WARNING
Risk of injury caused by the use
of incorrect pressing
attachments
▶ Only use pressing
attachments that correspond
to the diameter of the press-
fittings to be processed.
WARNING
Risk of fire from heat build-up
▶ Allow the pressing tool to cool
down for at least 30minutes
after 30minutes of continuous
operation.
▶ Do not place or store the hot
pressing tool near easily
flammable materials.
The pressing procedure can be
cancelled at any time. → See
"Cancelling the pressing procedure".
To improve ease of use, the pressing
head of the pressing tool can be
turned to any position up to 180°
before pressing. The pressing head
can only be rotated before the
pressing procedure.
Prerequisite
– Pipe ends are deburred and clean.
– The pipe section and pressfitting are
fitted together according to the
installation manual of the piping system.
– The pressing attachment is inserted
correctly.
