6.2 Fastening positions
115
325
115
A
B
115
375
115
A
B
Fissaggio a muro • Wall mounting • Fixation mural • Wandmontagee • Fijación en pared
Taglia 2
Size 2
Grandeur 2
Größe 2
Tamaño 2
Taglia 1
Size 1
Grandeur 1
Größe 1
Tamaño 1
(A) (B)
1-2 3
4-5
Taglie • Sizes • Grandeurs • Größen • Tamaños :
6.5
7.5
6.5
8.5
14
Recommended screws for fastening
Size 1 (ADL5...-1...) 
Size 2 (ADL5...-2...) 
Note! Other dimensions see chapter "4.10 Weights and dimensions" on page 17.
