ADL500 • Quick installation guide - Specifications and connection 65
Step 1 – Setting communication
Set the type of communication to be used.
STARTUP WIZARD
Set comm mode?
E=Yes Down=Next
E
01 /03
PAR: 4000
Communication mode
Parallel I/O
Value: 0
E
01 /03
PAR: 4000
Communication mode
Parallel I/O
Value: 0
Available selections: (0) Parallel I/O, (1) CANopen
At the end of the procedure proceed to next step.
Step 2 – Setting encoder parameters
Set the following parameters for the encoder installed on the motor:
STARTUP WIZARD
Set encoder param?
E=Yes Down=Next
E
01 /07
PAR: 2102
Encoder supply
5.2 v
Def: 5.2
Range: 5.2 ... 20V
02 /07
PAR: 2132
Encoder mode
None
Value: 0
Available selections:
(0) None (default), (1) Digital, (2) Sinus,
(3) Sinus SINCOS, (4) Sinus ENDAT,
(5) Sinus BiSS, (6)
ENDAT,
(7) BiSS, (8) Sinus SSI
Step 3 – Setting motor parameters
Note !
Def: The factory (default) setting depends on the size of the drive that is connected. These values refer to the ADL5.-1055
STARTUP WIZARD
Set motor data?
E=Yes Down=Next
E
01 /09
PAR: 540
Control type
ASY SSC
Value: 0
Available selections:
(0) ASY SSC (Default)
(1) ASY FOC
02 /09
PAR: 2000
Rated voltage
400 v
Def: 400
Range: 230 ... 480V
03 /09
PAR: 2002
Rated current
11.8 a
Def: 11.8
Range: 1 ... 1500A
Caution
To Next Page
