ADL500 • Quick installation guide - Specifications and connection 79
Index Error message shown
on the display
Sub-code Description
32 Enable missing Condition: (for ADL550 only) occurs if, after Safety Enable signal, Enable is not activated within 4 seconds.
Solution:
• Check Enable signal.
• Check SAFETY connector, contacts 1 and 2.
• Check electrical level and current capability of Safety Enable signal.
33 ... 48 Plc1 fault
...
Plc16 fault
Condition: Enabled application developed in the IEC 61131-3 environment has found the conditions for generating this specific alarm to be true. The mean-
ing of the alarm depends on the type of application. For more information, refer to the documentation concerning the specific application.
XXXXH-X The XXXXH-X code indicates the reason for the error: make a note of this to discuss it with the service centre.
Solution: Refer to the documentation concerning the enabled application.
With regards to the standard application EFC refer to Functional Parameter Manual section 5.10 LIFT ALARMS. For the applications DCP3/DCP4, EPC and
CiA 417 refert to the application manual section ALARMS.
49 Watchdog Condition: this condition can occur during operation when the watchdog micro protection is enabled; the alarm is included in the list of alarms and alarm
log. After this alarm:
- the drive automatically runs a reset
- motor control is not available.
XXXXH-X The XXXXH-X code indicates the reason for the error: make a note of this to discuss it with the service centre.
Solution: If the alarm is the consequence of a change in the drive configuration (parameter setting, option installation, PLC application download)
remove it.
Turn the drive off and then on again.
50 Trap error Condition: this condition can occur during operation when the trap micro protection is enabled; the alarm is included in the list of alarms and alarm log.
After this alarm:
- the drive automatically runs a reset
- motor control is not available.
XXXXH-X The XXXXH-X (SubHandler-Class) code indicates the reason for the error: make a note of this to discuss it with the service centre.
Solution: If the alarm was a consequence of a variation to the drive configuration (parameter setting, installation of an option, downloading of a PLC
application), remove it.
Switch the drive off and then switch it on again.
51 System error Condition: this condition can occur during operation when the operating system protection is enabled; the alarm is included in the list of alarms and alarm
log. After this alarm:
- the drive automatically runs a reset
- motor control is not available.
XXXXH-X The XXXXH-X (Error-Pid) code indicates the reason for the error: make a note of this to discuss it with the service centre.
Solution: If the alarm was a consequence of a variation to the drive configuration (parameter setting, installation of an option, downloading of a PLC
application), remove it.
Switch the drive off and then switch it on again.
52 User error Condition: this condition can occur during operation when the software protection is enabled; the alarm is included in the list of alarms and alarm log.
After this alarm:
- the drive automatically runs a reset
- motor control is not available.
XXXXH-X The XXXXH-X (Error-Pid) code indicates the reason for the error: make a note of this to discuss it with the service centre.
Solution: If the alarm was a consequence of a variation to the drive configuration (parameter setting, installation of an option, downloading of a PLC ap-
plication), remove it.
Switch the drive off and then switch it on again.
53 Param error Condition: if an error occurs during the enabling of the parameter database saved in the Flash memory; the alarm is included in the list of alarms and alarm
log.
XXXH-X Code XXXXH-X indicates the number of the parameter (Hex-Dec) that has caused the error: make a note of this to discuss it with the
service centre.
Solution: Set the parameter causing the error to the correct value and run Save parameter. Switch the drive off and then switch it back on again.
54 Load default Condition: this can occur during loading of the parameter database saved in the Flash memory
it is normal if it appears in the following conditions: the first time the drive is switched on, when a new version of the firmware is downloaded, when the
regulation is installed on a new size, when a new region is entered. If this message appears when the drive is already in use it means there has been a
problem in the parameter database saved in the Flash memory.
If this message is displayed the drive restores the default database, i.e. the one downloaded during production.
0001H-1 The database saved is not valid
0002H-2 The database saved is not compatible
0003H-3 The saved database refers to a different size and not to the current size
0004H-4 The saved database refers to a different region and not to the current region
Solution: Set the parameters to the desired value and execute Save parameters
55 Plc cfg error Condition: this can occur during loading of the MDPLC application
The Mdplc application present on the drive is not run.
0004H-4 The application that has been downloaded has a different Crc on the DataBlock and Function table.
0065H-101 The application that has been downloaded has an invalid identification code (Info).
0066H-102 The applciation that has been downloaded uses an incorrect task number (Info).
0067H-103 The application that has been downloaded has an incorrect software configuration.
0068H-104 The application that has been downloaded has a different Crc on the DataBlock and Function table.
0069H-105
A Trap error or System error has occurred.
The drive has automatically executed a Power-up operation.
Application not executed.
See the Alarm List for more information about an error that has occurred.
006AH-106 The application that has been downloaded has an invalid identification code (Task).
006BH-107 The application that has been downloaded uses an incorrect task number (Task).
006CH-108 The application that has been downloaded has an incorrect Crc (Tables + Code)
Solution: Remove the MDPLC application or download a correct MDPLC application.
