gefran ADV20 series User Manual

16 ADV20 QS, V1.02
Italiano English
Parameter Explanation Settings
Factory
Setting
NOTE
04.10
Digital Terminal
Input Debouncing
Time
1 to 20 (*2ms) 1
04.11 Min AVI Voltage 0.0 to 10.0V 0.0
04.12 Min AVI Frequency 0.0 to 100.0% 0.0
04.13 Max AVI Voltage 0.0 to 10.0V 10.0
04.14 Max AVI Frequency 0.0 to 100.0% 100.0
04.15 Min ACI Current 0.0 to 20.0mA 4.0
04.16 Min ACI Frequency
0.0 to 100.0%
0.0
04.17 Max ACI Current 0.0 to 20.0mA 20.0
04.18 Max ACI Frequency 0.0 to 100.0% 100.0
04.19
|
04.25
Reserved
04.26
Display the Status of
Multi-function Input
Terminal
Read only.
Bit0: MI1 Status
Bit1: MI2 Status
Bit2: MI3 Status
Bit3: MI4 Status
Bit4: MI5 Status
Bit5: MI6 Status
##
a04.27
Internal/External
Multi-function Input
Terminals Selection
0~4095 0
a04.28
Internal Terminal
Status
0~4095 0
Group 5 Multi-Step Speed Parameters
a05.00 1st Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.01 2nd Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.02 3rd Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.03 4th Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.04 5th Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.05 6th Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.06 7th Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.07 8th Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.08 9th Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.09 10th Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.10 11th Step Speed
Frequency
0.00 to 600.0 Hz 0.00
a05.11 12th Step Speed
Frequency
0.00 to 600.0 Hz 0.00
