User Guide Electrical Line Shaft for ADV200 Page 20 of 72
Parameter Name
User type
Value
Unit
Min
Max
Access
11022 Els Mech Ratio
Float
1.000
-
-200
+200
RWZ
Ratio of number of mechanical revs of fast Master shaft (motor) to number of mechanical revs of fast Slave shaft (motor).
This parameter has to be set in case of non-finite mechanical ratios. Otherwise, you can maintain default value = 1
11024 Els Mech Ratio Mul
Long
1
-
1
32000
RWZ
Multiplier of Els Mech Ratio.
This parameter has to be set in case of finite mechanical ratios. It indicates the number of revs of the fast reference
master shaft.
11026 Els Mech Ratio Div
Long
1
-
1
32000
RWZ
Divisor of Els Mech Ratio.
This parameter has to be set in case of finite mechanical ratios. It indicates the number of revs of the fast slave shaft
compared to the master revs set in Els Mech Ratio Mul.
12030 Els Act Mech Ratio
Float
-
-
-
-
R
Monitor of value of mechanical ratio used, equivalent to



