User Guide Electrical Line Shaft for ADV200 Page 28 of 72
12096 Els Master R Pos mon
Long
-
cnt
-
-
ER
12096 Position of reference master in position rev with respect to Engage point.
12098 Els Engage Reac mon
Boolean
-
-
-
-
R
Monitor of Engage state ended and slave shaft in synchronism with its reference master.
12100 Els Slave R Rev mom
Long
-
ER
Number of revs of commanded position of slave with respect to Engage point.
12102 Els Slave R Pos mon
Long
-
cnt
-
-
ER
Position in rev of the commanded position of slave with respect to Engage point.
12104 Els Engage S Loss
Long
-
u.u.
-
-
ER
Monitor of space lost during Engage ramp.
12140 Els Engage Speed mon
Float
-
rpm
-
-
R
Monitor of slave synchronism speed reference.
12142 Els End Ramp Spd mon
Float
-
rpm
-
-
ER
Monitor of slave speed at point of synchronism with master (end of acceleration ramp).
