gefran ADV200 User Guide

_____ _
User Guide Electrical Line Shaft for ADV200 Page 27 of 72
Parameter Name
User type
Value
Unit
Min
Max
Access
11134 Els Engage Mode sel
Enumerative
Ramp (def)
Recovery
-
-
-
RWZ
Selector for engage mode in electric line shaft.
In Ramp mode, on the rising edge of the Engage command (Els Engage mon = On), the slave goes to electric line shaft
with the master using the acceleration ramp set in Els Engage Acc Time.
At the end of the acceleration ramp, the reaching of synchronism is signaled in monitor variable Els Engage Reac mon.
In Recovery mode and with the Engage command active (Els Engage mon = On), the drive goes into a waiting state for
the start of synchronism. On the edge of the Els Recovery trigger signal (Els Recovery mon = On), the slave goes to
electric line shaft with the master using the acceleration ramp set in Els Engage Acc Time and recovers the space lost
starting from the edge of the trigger. When the slave has recovered all of the space lost from the master and is in
synchronism, the condition is signaled in monitor variable Els Engage Reac mon.
11136 Els Engage src
Enumerative
Null (def)
Dig inp x
Decomp
Dig inp x X
-
-
-
RWZ
Selector for source of Engage command; the action activates on the edge of the command and remains at the level.
If Els Engage Mode sel = Ramp, the engage sequence is started on the edge of the command; if the command is
withdrawn the sequence is aborted.
If Els Engage Mode sel = Recovery, on the edge of the command the system goes into a waiting state for the Els
recovery mon, if the command is withdrawn the sequence is aborted.
11138 Els Recovery src
Enumerative
Null (def)
Fx rising/falling
Dig inp x
Decomp
Dig inp x X
-
-
-
RWZ
Selector for source of command to start synchronism with space recovery. Active on edge, does not require maintenance
at level. The command is valid only in Els Engage Mode sel = Recovery mode.
11140 Els Engage Acc Time
Float
1.00
s
0.01
10
RW
Acceleration time used for Engage function and for Recovery profile. Set value corresponds to the time needed to go from
0 to Speed ref top lim (IPA 670 on REFERENCES menu).
11142 Els Engage Dec Time
Float
1.00
s
0.01
10
RW
Deceleration time used to stop a motor previously in electric line shaft and for Recovery profile. Set value corresponds to
the time needed to go from Speed ref top lim (IPA 670 on REFERENCES menu) to 0.
11152 Els Engage Reac dest
Enumerative
Null (def)
Pad from 1 to 16
-
-
-
ERWZ
Selector for destination of state monitor of Els Engage Reac mon.
11154 Els Recovery Speed
Float
100
rpm
0
IPA
670
RW
Overspeed in [rpm] of space profile for phase recovery during Engage acceleration ramp in Els Recovery Mode =
Speed.
11206 Els Recovery Mode
Enumerative
Speed (def)
Speed %
ERW
Overspeed mode of space profile for phase recovery during Engage acceleration ramp.
If Speed: overspeed is set in [rpm] in parameter Els Recovery Speed
If Speed %: overspeed is expressed as % in parameter Els Recovery Speed %.
11208 Els Recovery Speed %
Float
10
%
10
100
ERW
Overspeed of space profile for phase recovery during Engage acceleration ramp in Els Recovery Mode =Speed %.
Speed is expressed as % of Engage speed of slave shaft, understood as speed at point of synchronism with master.
This speed is monitored in parameter Els End Ramp Spd mon.
12074 Els Engage mon
Boolean
-
-
-
-
R
Monitor of state of digital Engage command.
12076 Els Recovery mon
Boolean
-
-
-
-
R
Monitor of state of digital Recovery command. If linked to a freeze input, On state persists for only 1 ms.
12094 Els Master R Rev mon
Long
-
-
-
-
ER
Number of revs of reference master position with respect to Engage point.
