4-20
Error 6 verification time
09-09
Drive Transmit
(
)
5 ~ 65
5 2ms
Group10- PID function Setup
No. Description Range
Factory
Unit Note
10-00
PID target value selection
(when 00-05\00-06=6,
this function is enabled)
0:Potentiometer on Keypad
1: Analog Signal Input. (AVI)
2: Analog Signal Input. (ACI)
3: Frequency set by communication
4: Keypad Frequency parameter 10-02
1 - *1
10-01
PID feedback value
selection
0: Potentiometer on Keypad
1: Analog Signal Input. (AVI)
2: Analog Signal Input. (ACI)
3: Communication Setting Frequency
2 - *1
PID Target (keypad input)
10-03
PID Mode Selection
1: Deviation D Control.
FWD Characteristic.
2: Feedback D Control
FWD Characteristic.
3: Deviation D Control
Reverse Characteristic.
4: Feedback D Control
Reverse Characteristic.
5: Frequency Command + Deviation D Control.
FWD Characteristic.
6: Frequency Command + Feedback D Control
FWD Characteristic.
7: Frequency Command + Deviation D Control
Reverse Characteristic.
8: Frequency Command + Feedback D Control
0 -
10-04
Feedback Gain
0.00 ~ 10.00 1.00 % *1
10-08
PID Offset
0: Positive
0 - *1
10-10
PID Output Lag Filter
0.0 ~ 2.5 0.0 s *1
10-11
Feedback Loss Detection
Mode
1: Enabled - Drive Continues to Operate After
Feedback Loss
2: Enabled - Drive "STOPS"
0 -
10-12
Feedback Loss Detection
Level
0 ~ 100
0 %
10-13
Feedback Loss Detection
Delay Time
0.0 ~25.5
1.0 s
