gefran BDI50-3037-KBX-4-NP-F User Manual

4-21
Group10- PID function Setup
No. Description Range
Factory
Setting
Unit Note
10-15
Integral Value Resets to
Zero when Feedback
Signal Equals the Target
Value
0:Disabled
1: 1 Second
30: 30 Seconds (0 ~ 30)
0 -
10-16
Allowable Integration
Error Margin (units)
(1unit = 1/8192)
0 ~ 100
0 -
10-17
PID Sleep Frequency
Level
0.00~599.00
0.00 Hz
10-18
PID Sleep Function Delay
Time
0.0 ~25.5
0.0 s
10-19
PID Wake up frequency
Level
0.00 ~ 599.00
0.00 Hz
10-20
PID Wake up function
Delay Time
0.0 ~ 25.5 0.0 s
10-21
Max PID Feedback
Setting
0 ~999
100 - *1
10-22
Min PID Feedback Setting
0 ~999
0
-
*1
Group11- Performance Control functions
No. Description Range
Factory
Setting
unit Note
11-00
Reverse operation control
0: Reverse command is enabled
1: Reverse command is disabled
0 -
11-01
Carrier Frequency (kHz)
1~16
5
KHz
11-02
Carrier mode Selection
0: Mode0, 3ph PWM modulation
1: Mode1, 2ph PWM modulation
2: Mode2, random PWM modulation
1 -
11-03
Carrier Frequency
Reduction by temperature
rise
0: disabled
1: enabled
0 -
11-04
S-Curve Acc 1
0.0 ~ 4.0
0.00
s
11-05
S-Curve Acc 2
0.0 ~ 4.0
0.00
s
11-06
S-Curve Dec 3
0.0 ~ 4.0
0.00
s
11-07
S-Curve Dec 4
0.0 ~ 4.0
0.00
s
11-08
Skip Frequency 1
0.00 ~ 599.00
0.00
Hz
*1
11-09
Skip Frequency 2
0.00 ~ 599.00
0.00
Hz
*1
11-10
Skip Frequency 3
0.00 ~ 599.00
0.00
Hz
*1
11-11
Skip Frequency
Bandwidth (±)
0.00 ~ 30.00 0.00 Hz *1
11-12
Reserved
11-13
Regeneration Prevention
Function
0: Disable
1: Enable
2: Enable (during constant speed only)
0 -
11-14
Regeneration Prevention
Voltage Level
200V: 300.0~400.0
400V: 600.0~800.0
380/760 V
11-15
Regeneration Prevention
Frequency Limit
0.00～15.00 3.00 Hz
11-16
Regeneration Prevention
Voltage Gain
0~200 100 %
11-17
Regeneration Prevention
Frequency Gain
0~200 100 %
11-18
Speed loop proportion
gain
0~65535 10000

gefran BDI50-3037-KBX-4-NP-F Specifications

General

Brand	gefran
Model	BDI50-3037-KBX-4-NP-F
Category	Inverter
Language	English
