6 • TECHNICAL CHARACTERISTICS
Processors • Intel PentIum Celeron
tm
600 mHz (2mb CaCHe l2)
• Intel Celeron mobIle
tm
1500 mHz (2mb CaCHe l2)
chiPset • Intel 852GM, 400 MHz FSB
Video controller • Intel extreme GraPHICs 2 Controller (fIno a 64mb Dram VIDeo)
disPlay (Only for DIGISTAR II and DIGISTAR II Control)
• 10,4” colors TFT res. 800x600 pixel, 262K col.; view corner 120° / 100° H/V,
contrast 500:1, Luminosity 230 cd/m2
• 12,1” colors TFT res. 800x600 pixel, 262K col.; view corner 140° / 110° H/V,
contrast 500:1, Luminosity 600 cd/m2
• 15” colors TFT res. 1024x768 pixel, 262K col.; view corner 130° / 120° H/V,
contrast 500:1, Luminosity 350 cd/m2
dynaMic raM • DDR 256 MB
• DDR 512 MB
• DDR 1024 MB
static raM • 256Kb with battery backup (lithium)
Mass sSD
MeMory • DOM 128 Mb (Only for DIGISTAR II Control and GF-BOX)
• DOM 1 Gb (Only for GF-BOX and DIGISTAR II)
• DOM 2 Gb (Only for GF-BOX and DIGISTAR II)
• DOM 4 Gb (Only for GF-BOX and DIGISTAR II)
hD
• HD 2.5“ IDE optional. (Only for DIGISTAR II and GF-BOX)
Watch dog • Timer with generation of hardware reset.
Port i/o custoM • Serial synchronous port for management of matrixes max 128 keys and 64 leds
• Logical output 24Vdc open collector max 100mA opto-insulated for programmable timed
switch, can be activated also when the system is switched off.
Keyboard (Only for DIGISTAR II and DIGISTAR II Control)
• 10 function keys
• 2 operative keys TAB, ENTER
• Expandable through use of the DIGITAST keyboard
exPansions • 1 Slot PCI (Only for GF-BOX and DIGISTAR II)
• 1 Slot PC104 16 Bit (max 3 cards)
• 4 Slot custom GEFRAN
GEFRAN exPansion • Module GT-SER2: 2 serial ports RS232/RS422/RS485 opto-insulated
Cards • Module GT-CAN1: 1 channel CAN L2 opto-insulated (Escluso DIGISTAR II)
• Module GT-CAN2: 2 channels CAN L2 opto-insulated
• Module GT-ETH1: 1 channel Ethernet
• Module GT-ETH2: 2 channels Ethernet
PoWer suPPly • 18..36 Vdc 2.5A max. with protection of polarity
• Short circuit protection with re-settable PTC
• On-off switch
oPerating systeM • VxWorks (Only for GF-BOX and DIGISTAR II Control)
• Microsoft™ Windows™ XPPro™ MUI Pack (Only for DIGISTAR II and GF-BOX)
• Microsoft™ Windows™ XP Embedded™ (english) (Only for DIGISTAR II and GF-BOX)
enViroMental • Protection IP 65 front panel
aMbiental condition • Operating temperature: Model PCE 600MHz: 0°C..+50°C
Model PCS 1500MHz: 0°C..+45°C
• Storage temperature -10°C..+70°C
• 90% Max. humidity non condensing
diMensions and DIGISTAR II and digistar ii control GF-BOX
Weight • With display 10,4”: 309x239x117 mm - 4Kg max • 300x205x90 mm - 2,5 Kg max
• With display 12,1”: 335x295x117 mm - 5Kg max
• With display 15”: 395x340x117 mm - 7Kg max
ConforMity
In conformity to ECC 2004/108/CE (EMC) and 2006/95/CE (LVD) with reference to:
EN 61131-2 (product) EN 61010-1 (safety).
