DIGISTAR II: MECHANICAL CHARACTERISTICS AND DIMENSIONS
DIGISTAR II 15”
361,3
365
110,96
307
337
116,9
395,3
DIGISTAR II : INSTALLATION AND FIXING SYSTEM
The installation system is the same for both 10,4”, 12.1”,15” DIGISTAR II and DIGISTAR II Control with display
versions.
After having carried out the housing according to the template indicated in the drawing, insert the DIGISTAR II
from the front, prepare the relative fixing blocks into the respective housings and screw down.
