gefran SIEIDrive ADV50 Series User Manual

ADV50 QS, SW-PW V1.11 / CTL V2.11 5
Italiano English
+
-
Please use brake unit and/or
brake resistor depending on
type and application
Braking unit
(optional)
BUE
BR
braking resistor
(optional)
Figure 1 for models :
ADV50-1004-...-..., ADV50-1007-...-...
Please use brake unit and/or
brake resistor depending on
type and application
+/B1
-
BUE
braking unit (optional)
BR
braking resistor (optional)
BR
B2
Figure 2 for models :
ADV50-2015-...-2M-F, ADV50-2022-..., ADV50-2037-..., ADV50-2055-..., ADV50-2075-...,
ADV50-3110-...-...
Figure 4 Wiring for NPN mode and PNP mode
A. NPN mode without external power B. NPN mode with external power
Factory
setting
NPN
PNP
Factory
setting
NPN
PNP
24
Vdc
-
+
C. PNP mode without external power D. PNP mode with external power
Sw1
Factory
setting
NPN
PNP
Sw1
Factory
setting
NPN
PNP
24
Vdc
-
+
