RS5/6-34 Telescopic Handler HYDRAULICS
HYDRAULIC SPECIFICATIONS
Pump Output ........................................................................................................ 29 GPM (110 L/min) at 2500 RPM
Pump Flow Divider Priority Flow..................................................................................................... 8 GPM (30 L/min)
Flow Divider (Joystick Control and Park Brake Pressure)
Relief Valve ....................................................................................................................................350 psi (24 bar)
Pump (Steering)
Modulation Relief Valve .............................................................................................................2000 psi (172 bar)
Service Brake Valve Modulation Pressure .........................................................................................435 psi (30 bar)
Main Control Valve Relief Valve .....................................................................................................3000 psi (207 bar)
Attachment Tilt Up Relief Valve......................................................................................................3000 psi (207 bar)
Attachment Tilt Down Relief Valve .................................................................................................3000 psi (207 bar)
Auxiliary Valve Relief Valves ..........................................................................................................2500 psi (172 bar)
Reservoir Capacity ................................................................................................................. 35 Gallons (133 Liters)
