Filling volume:
Actuator version
code
Filling volume Piston diameter
0G1, 0M1 0.006 dm³ 28 mm
1G1, 1M1 0.025 dm³ 42 mm
2G1, 2M1 0.084 dm³ 60 mm
3G1, 3M1 0.245 dm³ 80 mm
4G1 0.437 dm³ 100 mm
5G1 0.798 dm³ 130 mm
Leakage rate: Leakage rate A to P11/P12 EN 12266-1
Pressure/temperature
correlation:
Connection
types
code
1)
Material
code
2)
Max. allowable operating pressures in bar at temperature in °C
)
RT 100 150 200 250 300
1, 9, 17, 37,
60, 63, 3C,
3D
37 25.0 23.8 21.4 18.9 17.5 16.1
0, 16, 17, 37,
59, 60, 65
34 25.0 24.5 22.4 20.3 18.2 16.1
13 (DN 15 -
DN 50)
34 25.0 23.6 21.5 19.8 18.6 17.2
80, 88 (DN
15 - DN 40)
34 25.0 21.2 19.3 * - - -
80, 88 (DN
50 - DN 80)
34 16.0 16.0 16.0 * - - -
82 (DN 15 -
DN 32)
34 25.0 21.2 19.3 * - - -
82 (DN 40 -
DN 65)
34 16.0 16.0 16.0 * - - -
86 (DN 15 -
DN 40)
34 25.0 21.2 19.3 * - - -
86 (DN 50 -
DN 65)
34 16.0 16.0 16.0 * - - -
10 (DN 15 -
DN 50)
37 25.0 25.0 22.7 21.0 19.8 18.5
47 (DN 15 -
DN 50)
34 15.9 13.3 12.0 11.1 10.2 9.7
0, 16, 17, 59,
60
40 25.0 20.6 18.7 17.1 15.8 14.8
17, 59, 60 C2 25.0 21.2 19.3 17.9 16.8 15.9
* max. temperature 140 °C
All pressures are gauge pressures.
The valves may be used to -10 °C
GEMÜ 550www.gemu-group.com 15 / 46
7 Technical data
