MAIN POWER CONNECTOR
NOTICE
Damage to electrical connections and components will occur if they are
unplugged before the main power connector is disconnected. Always
disconnect the main power connector before servicing or unplugging any
electrical components.
WARNING
Insulate any tools used within the battery area to prevent sparks or battery
explosion caused by shorting the battery terminals or wiring. Remove the
batteries, or cover the exposed terminals with an insulating material.
When disconnected, the main power
connector disconnects the battery pack
from all electrical components, with the
exception of the contactor. After
servicing the vehicle, the main power
connector should be the last connection
to be made. The main power connector
is located behind the seat on the
passenger side of the vehicle, under the
rear bed, adjacent to the main line
contactor. To disconnect, unplug the
connector.
37
FEATURES AND CONTROLS
