GEM eM1400 LSV 2020 - Maintenance; Battery Charging

INDICATOR PANEL LAMP REPLACEMENT
In the event that the indicator panel fails
to illuminate, check to see if you have
an expired lamp.
To replace the indicator panel lamp, do
the following:
1. Lift the hood.
2. Reach in behind the console panel and lift the release
q
to unplug the light
from the harness.
3. Using a flathead screwdriver, press on the tab
w
on the top of the light to
remove the indicator light assembly from the console panel.
4. Locate the expired lamp. Using a screwdriver, rotate the lamp 1/4 turn
counter-clockwise.
5. Grip the lamp with a needle-nose pliers and remove it from the assembly.
6. Install the new lamp. Using a screwdriver, rotate the lamp 1/4 turn clockwise
to seat it.
7. Snap the assembly back into the console panel. Reconnect the harness.
8. Close the hood.
80
MAINTENANCE
