5 Order data
The order data provide an overview of standard configurations.
Please check the availability before ordering. Other configurations available on request.
Order codes
1 Type Code
Pinch valve, pneumatically operated,
plastic piston actuator
Q30
2 Tube inside diameter Code
3.180 mm (1/8") inside diameter 2
6.350 mm (1/4") inside diameter 4
9.530 mm (3/8") inside diameter 6
12.700 mm (1/2") inside diameter 8
19.050 mm (3/4") inside diameter 12
25.400 mm (1") inside diameter 16
3 Tube outside diameter Code
6.350 mm (1/4") outside diameter DA
9.530 mm (3/8") outside diameter DC
11.110 mm (7/16") outside diameter DD
12.700 mm (1/2") outside diameter DE
15.880 mm (5/8") outside diameter DG
19.100 mm (3/4") outside diameter DH
22.230 mm (7/8") outside diameter DI
28.580 -29.970 mm (1 1/8- 1 3/16") outside dia-
meter
DK
35.690 - 38.100 mm (1 13/32- 1 1/2") outside dia-
meter
DN
4 Tube carrier version Code
Plastic design, stainless steel tube carrier and
PA tube holder
7P
Plastic design, PA tube carrier and
PA tube holder
PA
5 Control function Code
Normally closed (NC) 1
Normally open (NO) 2
6 Actuator version Code
Actuator size 0P1 0P1
Actuator size 1P1 1P1
Actuator size 2P1 2P1
7 Mounting option Code
Without mounting flange, with 4 x threaded hole in
body
0
With mounting flange at bottom FB
With mounting flange above FT
8 CONEXO Code
Without
Integrated RFID chip for electronic identification
and traceability
C
Order example
Ordering option Code Description
1 Type Q30 Pinch valve, pneumatically operated,
plastic piston actuator
2 Tube inside diameter 8 12.700 mm (1/2") inside diameter
3 Tube outside diameter DH 19.100 mm (3/4") outside diameter
4 Tube carrier version PA Plastic design, PA tube carrier and
PA tube holder
5 Control function 1 Normally closed (NC)
6 Actuator version 1P1 Actuator size 1P1
7 Mounting option FT With mounting flange above
8 CONEXO Without
5 Order data
www.gemu-group.com 7 / 19 GEMÜ Q30
