21 TRANSPARENT ELECTROLUMINESCENT DISPLAY
SPECIFICATIONS
The Gemini 810 + 980 diode laser is designed with a unique transparent electroluminescent display,
which produces high-resolution images that can be viewed from a field of vision up to 170 degrees.
The transparent display was specially designed with over 80% transparency and an arch of 32 degress
for optimal viewing angle from any direction. The light is generated by a thin film—less than a micron
thick— of specially designed electroluminescent phosphor.
Display type: Electroluminescent
Transparency: 92%
Brightness: 300 cd/m^2
Color: Broadband Yellow
Peak Wavelength: 582 nm
Voltage: ~180V AC
Response time: 1.8 ms
Glass type: Float Glass
Glass thickness: 1.1 mm fused
Thin Film Thickness: 1 micron
29
CONTROLS, OPERATION & USE
DO NOT GRAB DISPLAY THIS WAY GRAB UNIT BY THE NECK
