Gemini 810 - System Specifications

Gemini 810 + 980 Diode Laser
THE GEMINI 810 + 980 DIODE LASER COMPLIES WITH THE FOLLOWING
Dimensions of Foot Pedal: 6.1” (L) x 5.0” (W) x 4.1” (H) - 15.5 cm(L) x 12.7 cm (W) 10.4 m (H)
Weight: 2.2 lbs - 1.0 Kg
Laser classification: Class IV laser device
Delivery system: Optical Fiber
Wavelength: 810 nm or 980 nm ± 10 nm
Dual Wavelength ± 10 nm (50% @ 810 nm / 50% @ 980 nm)
Maximum power: 810 nm @ 2.0 Watts ± 20%
980 nm @ 2.0 Watts ± 20%
Dual Wavelength @ 2.0 Watts ± 20%
Aiming beam wavelength: 650 ± 10 nm
Aiming beam power: 5mW max
Beam divergence: 617 mrad
Power range: 0.1 Watt to 2.0 Watts Average
Pulse frequency: 50 Hz
Pulse width : Variable
Duty cycle: Variable
Voice confirmation: YES
Power requirements: 100-240 VAC @ 50 to 60 Hz - 13V
Current: 4.0 Amps
Battery: 11.1V Rechargeable Lithium Ion
Wireless frequency: Bluetooth at 2.4 GHz
Maximum Operating Altitude: 5,000 meters or 16,404 feet
SYSTEM SPECIFICATIONS
• IEC 60825-1
• EN/ES 60601-1
• IEC 60601-1-2
• IEC 60601-2-22
• 21 CFR 1040.10 and 1040.11
• FCC parts 15 and 18 (47 CFR)
38
Dimensions of Laser Unit: 6.7” (L) x 6.6” (W) x 10.1” (H) - 17.2 cm (L) x 17.0 cm (W) 25.7 cm (H)
