GEMORO TESTEROSSA 22 23
14. Using the Test Stone Magnifier:
This accessory will allow you to
see a magnified view of the stone
being tested and help ensure that
you’re making proper contact with
the probe tip and stone while not
accidentally touching the setting
or prongs. After removing the
testers probe tip cap, take the Test
Stone Magnifier’s wider side of its
oval shaped frame and insert it
over the TESTEROSSA’s probe tip
cone in the direction of the arrows
inside of the frame and clip it into
place. Depending on whether you
are right or left handed, you may
conveniently position it on either
side of the tester. Pivot the hinged
magnifier so that it is positioned
in front of the testers probe tip.
You may now view the stones you
are testing under magnification
P
. To remove the Test Stone
Magnifier, carefully grasp it
near the oval shaped frame
for leverage and with a slight
twisting motion it will expand
the opening on the frame so you
may then gently pull it off
Q
.
MAINTENANCE:
1. The TESTEROSSA is not user
serviceable other than battery
replacement, probe tip cleaning,
and recalibration. If service is
required, please contact your
supplier or the factory. Any other
attempt to repair the tester by
a user will void the warranty.
2. Always replace the protective
probe tip cap to keep the probe
tip from becoming damaged.
3. If using alkaline batteries, always
replace the batteries after long
periods of time to prevent
premature corrosion or battery
TESTER IN ULTRADOCK 3
HOW TO USE THE MAGNIFIER
HOW TO REMOVE THE MAGNIFIER
O
P
Q
