Control medium
Inert gases
Max. permissible temperature of control medium 60 °C
Filling volume
Diaphragm
size
DN
Actuator
size
Actuator
version
Spring set
Control
function 1
Control
function 2
8 4 to 15 0
T/R 1 0.01 dm³ 0.01 dm³
T/R A 0.02 dm³ 0.01 dm³
10 10 to 20 1 T/R/D/B 1 0.03 dm³ 0.07 dm³
25 15 to 25 2 T/R/D/B 1 0.13 dm³ 0.22 dm³
40 32 to 40 3
T/R/D/B 1 0.23 dm³ 0.50 dm³
T/R A 0.50 dm³ -
50 50 to 65 4 T/R/D/B 1 0.50 dm³ 1.20 dm³
80 65 to 80 5
T/R 1 2.68 dm³ 3.20 dm³
T/R A/B 2.13 dm³ -
100 100 6
T/R 1 2.78 dm³ 3.40 dm³
T/R A 2.15 dm³ -
150 150 8 T A 5.30 dm³ -
C.f. 3 = for filling volume in open position see c.f. 1; for filling volume in closed position see c.f. 2
Operating pressure [bar]
MG DN
Control
function
Actuator
version
EPDM PTFE
Diaphragm
material
All valve
body
materials
Diaphragm
material
Forged and
block material
bodies
Investment
cast body
8 4 to 15
1
0T1, 0R1
13, 17, 19,
36
0 to 8
54
0 to 6 0 to 6
0TA, 0RA 0 to 10 0 to 10 0 to 6
2 + 3
0T1, 0R1,
0TA, 0RA
0 to 10
0 to 10 0 to 6
0 to 10 0 to 6
10 10 to 20
1
1T1, 1R1
13, 17, 19,
36
0 to 10
54
0 to 10 0 to 6
1D1, 1B1 0 to 10 0 to 6 0 to 6
2 + 3
1T1, 1R1 0 to 10 0 to 10 0 to 6
1D1, 1B1 0 to 10 0 to 6 0 to 6
25 15 to 25
1
2T1, 2R1
13, 17, 19,
36
0 to 10
54, 5M
0 to 10 0 to 6
2D1, 2B1 0 to 10 0 to 6 0 to 6
2 + 3
2T1, 2R1 0 to 10 0 to 10 0 to 6
2D1, 2B1 0 to 10 0 to 6 0 to 6
40 32 to 40
1
3T1, 3R1,
3D1, 3B1
13, 17, 19,
36
0 to 10
54, 5M
0 to 6 0 to 6
3TA, 3RA - 0 to 10 0 to 6
2 + 3
3T1, 3R1 0 to 10 0 to 10 0 to 6
3D1, 3B1 0 to 10 0 to 6 0 to 6
50 50 to 65
1
4T1, 4R1
13, 17, 19,
36
0 to 10
54, 5M
0 to 10 0 to 6
4D1, 4B1 0 to 10 0 to 6 0 to 6
2 + 3
4T1, 4R1 0 to 10 0 to 10 0 to 6
4D1, 4B1 0 to 10 0 to 6 0 to 6
80 65 to 80
1
5T1, 5R1
13, 17, 19,
36
0 to 8
54, 5M
0 to 5 -
5TA, 5RA - 0 to 10 -
5TB, 5RB 0 to 10 - -
2 + 3 5T1, 5R1 0 to 10 0 to 10 -
100 100
1
6T1, 6R1
13, 17, 19,
36
0 to 6
54, 5M
0 to 4 -
6TA, 6RA 0 to10 0 to 10 -
2 + 3 6T1, 6R1 0 to 10 0 to 10 -
150 150 1 8TA, 8RA - - 5Q 0 to 10 -
All pressures are gauge pressures. Operating pressure values were determined with static operating pressure applied on one side of a closed valve. Sealing at
the valve seat and atmospheric sealing is ensured for the given values.
Information on operating pressures applied on both sides and for high purity media on request
MG = diaphragm size
