Gemu 650 - Sectional Drawings and Spare Parts

20 Sectional drawings and spare parts
Item Name Order designation
Diaphragm sizes 8 - 50 / Actuator version: T
1 Valve body K600...
2
Diaphragm 600...M
18
Bolt
}
650...S30...
19
Washer
20 Nut
A Actuator 9650...
Vent for c.f.
NC /
diaphragm
size 8
A
2
1
19
18
Leak detection hole
19
20
Vent hole for c.f.
NC /
diaphragm sizes
10 - 50
Connector 2
46 / 52
650
