Gemu 650 - Page 47

A
2
1
19
18
Leak detection hole
Vent hole
for c.f. NC /
diaphragm sizes 10 - 50
Connector 2
Item Name Order designation
Diaphragm sizes 10 - 50 / Actuator version: D
1 Valve body K600...
2
Diaphragm 600...M
18
Bolt
}
650...S30...
19
Washer
A Actuator 9650...
47 / 52
650
