Gemu 650 - Page 49

A
2
1
Leak detection
hole
19
20
Vent hole for c.f. NC
Connector 2
Item Name Order designation
Diaphragm size 100
1 Valve body K600...
2
Diaphragm 600...M
19
Washer
}
650...S30...
20
Nut
A Actuator 9650...
49 / 52
650
