System Operation (cont.):

Settings Menu:

To access the Settings menu, press and hold the Hi-Hat button. The Hi-Hat preset display identiﬁes the speciﬁc

setting to be adjusted, and the Cym5 display shows the current value of that setting.

Press Cym5 or to change the value of the current setting.

Press Hi-Hat or to scroll to the next setting.

To exit the Settings menu press and hold the Hi-Hat button. For most settings, the DCP will exit the Settings

menu automatically if no keys are pressed for several seconds.

Available Settings:

• Display Brightness (“br”) – Adjust the display brightness by pressing Cym5 or .

• Aux Input Volume (“Au”) – Adjust the level of signals mixed in via the Aux Input jack by pressing Cym5

or .

• MIDI Channel (“ch”) – Sets the base MIDI channel (1-8). The DCP requires 9 MIDI channels, starting with

the base channel. For example, if channel 1 is selected (the default value) then communication will take place

over channels 1- 9. The base channel selected in the DCP must match the base channel set in the DCP

Access Tool program. Both programs default to channel 1, and you should not need to change these settings

unless you are using other MIDI devices on the same MIDI bus at the same time.

• MIDI Device ID (“id”) – Sets the MIDI sysex device ID of the DCP when using the companion desktop DCP

Access Tool program to edit presets or upload ﬁrmware upgrades to the DCP. It defaults to 1, and the desktop

program’s device ID defaults to 0. You should not have to change this setting unless you have multiple DCPs on

the same MIDI bus, in which case each DCP should have a different device ID.
