Genelec 1030A Datasheet

1030A Data Sheet
Genelec Document BBA30001a. Copyright Genelec Oy 9.2003. All data subject to change without prior notice
International enquiries:
Genelec, Olvitie 5
FIN-74100, Iisalmi, Finland
Phone +358 17 83881
Fax +358 17 812 267
Email genelec@genelec.com
In the U.S. please contact
Genelec, Inc., 7 Tech Circle
Natick, MA 01760, U.S.A
Phone 508 652 0900
Fax 508 652 0909
Email genelec.usa@genelec.com
www.genelec.com
In China please contact:
Genelec China Representative Office
Soho New Town, 88 Jianguo Road
D-1504, Chaoyang District
Beijing 100022, China
Phone +86 10 8580 2180
Fax
+86 10 8580 2181
AMPLIFIER SECTION
CROSSOVER SECTION
SYSTEM SPECIFICATIONS
1030A
Lower cut-off frequency, -3 dB
< 52 Hz
Upper cut-off frequency, -3 dB
> 20 kHz
Free field frequency response
55 Hz - 18 kHz (± 2.5 dB)
Maximum short term sine wave acoustic
output on axis in half space, averaged
from 100 Hz to 3 kHz
@ 1 m
> 105 dB SPL
@ 0.5 m
> 111 dB SPL
Maximum long term RMS acoustic
output in same conditions with
IEC-weighted noise (limited by driver
@ 1 m
> 99 dB SPL
unit protection circuit)
@ 0.5 m
> 105 dB SPL
Maximum peak acoustic output per pair
@ 1 m from the engineer with music
material
> 115 dB
Self generated noise level in free field
@ 1 m on axis
< 10 dB (A-weighted)
Harmonic distortion at 90 dB SPL
Freq:
60...150 Hz
< 3%
@ 1 m on axis
> 150 Hz
< 0.5%
Drivers
Bass
170 mm (6 1/2") cone
Treble
19 mm (3/4") metal dome
Both drivers are magnetically shielded
Weight
7,6 kg (17 lb)
Speaker dimensions
Height
312 mm (12 1/4")
Width
200 mm ( 7 7/8")
Depth
240 mm (9 7/16")
Note that the cable connectors require additional
100 mm (4”) of space behind the speaker cabinet.
1030A
Bass amplifier output power with
an 4 Ohm load
Short term 80 W
Treble amplifier output power with
an 8 Ohm load
Short term 50 W
Long term output power is limited by driver unit
protection circuitry.
Amplifier system distortion at
THD
<
0.08%
nominal output
SMPTE-IM
<
0.08%
CCIF-IM
<
0.08%
DIM 100
<
0.08%
Signal to Noise ratio,
Bass
>
95 dB
referred to full output
Treble
>
95 dB
Mains voltage:
230, 100/200 or 115/230 V
according to region
Voltage operating range:
±10%
Power consumption
Idle
10 VA
Full output
100 VA
1030A
Input connector: XLR female
pin 1 gnd
pin 2 +
pin 3 -
Input impedance
10 kOhm balanced
Input level for 100 dB SPL output @ 1m
variable from +6 to -6 dBu
Input level for maximum short term sine
variable from +11 to -1 dBu
wave output of 105 dB SPL @ 1m
Subsonic filter below 50 Hz
18 dB/octave
Ultrasonic filter above 25 kHz
12 dB/octave
Crossover frequencies
Bass/Treble
3.5 kHz
Crossover acoustical slopes
24 - 32 dB/octave
Treble tilt control operating range in
+2 to -4 dB & MUTE
2 dB steps
Bass roll-off control operating range in
from 0 to -8 dB @ 50 Hz
2 dB steps
Bass tilt control operating range in
from 0 to -6 dB @ 100 Hz & MUTE
2 dB steps
The ‘CAL’ position is with all tone controls set to ‘off’
and input sensitivity control to maximum and
corresponds to a maximally flat free field response.

Genelec 1030A Specifications

General

Frequency Response	58 Hz - 20 kHz (±2.5 dB)
Amplifier Power (LF)	50 W
Amplifier Power (HF)	50 W
Type	Active Studio Monitor
Crossover Frequency	3 kHz
Maximum SPL	108 dB
Input	XLR
Driver Size	6.5 inch (woofer), 3/4 inch (tweeter)
