Genelec 1032A Brochure

12
www.genelec.com
Bag for 8020A
Soft transportation bag.
8020-421 Bag for 2
pcs 8020A.
Bag for 8030A
Soft transportation bag.
8030-421 Bag for 2 pcs
8030A / 8130A.
Bag for 8040A
Soft transportation bag.
8040-420 Bag for 2 pcs
8040A or 8240A.
Bag for 8050A
Soft transportation bag.
8050-420 Bag for one
8050A or 8250A.
Handle Strap
Carrying handle strap
for one monitor, incl. M6
screw. For all 8000-series
models.
8000-430 Handle strap
Active monitor hybrid cable
For several years the market has been requesting an easy-to-install cable for
active monitors. Genelec, in cooperation with Klotz Gmbh, has developed a
small and installation-friendly hybrid cable that features power and signal in
two isolated shield packed in the hybrid cable. Power is 3 x 0,85 mm
2
and
signal is double shielded 110 Ohm AES/EBU cable which can also handle
analogue signal.
1510-302B Hybrid cable black on 50 m reels only.
caRRYInG accessoRIes
cable
Hybrid Cable (1 x Digital-110ȍ + Power) - Zipcord
Hybrid Cable for active speakers
Signal Cable AWG 24/7 + Power 3 x 0.86 mm²
parallel zip construction
Composite
Order No. HD01P08
Z
Construction 1 x Audio + 1 x Power, parallel, splitabl
e
Jacket PVC, black
Dimensions 12.0 mm x 5.9 mm
Weight 97g/m
Working Temperature -25 °C / +70 °C
Signal Cable
Conducto
r
7 x 0.20 mm (AWG24) tinned copper Conductor Resistance < 85 ȍ/km
Conductor Area 0.22 mm² Capacitance 47 pF/m
Insulation Foam-Skin-PE Characteristic Impedance 110 ȍ
Shielding AL/PETP foil + tinned stranded drain wire + Attenuation / 100 m f = 1 MHz : 2.3 dB
tinned copper braid, coverage 85% f = 3 MHz : 3.9 dB
Jacket PVC, black, Ø 5.9 mm f = 10 MHz : 6.9 dB
Power Cable 3x0.85 mm²
Conducto
r
bare copper, 19 x 0.24mm Conductor Resistance 21 ȍ/km
Conductor Cross Section 0.86 mm² (AWG 18) Insulation Resistance > 10 Mȍ x km
Insulation PVC Rated Voltage 300/300 V
Number of Cores 3 Test Voltage 2 kV
Jacket PVC, black, Ø 5.9 mm
HD01P08Z
Hybrid Cable (1 x Digital-110ȍ + Power) - Zipcord
Hybrid Cable for active speakers
Signal Cable AWG 24/7 + Power 3 x 0.86 mm²
parallel zip construction
Composite
Order No. HD01P08
Z
Construction 1 x Audio + 1 x Power, parallel, splitabl
e
Jacket PVC, black
Dimensions 12.0 mm x 5.9 mm
Weight 97g/m
Working Temperature -25 °C / +70 °C
Signal Cable
Conducto
r
7 x 0.20 mm (AWG24) tinned copper Conductor Resistance < 85 ȍ/km
Conductor Area 0.22 mm² Capacitance 47 pF/m
Insulation Foam-Skin-PE Characteristic Impedance 110 ȍ
Shielding AL/PETP foil + tinned stranded drain wire + Attenuation / 100 m f = 1 MHz : 2.3 dB
tinned copper braid, coverage 85% f = 3 MHz : 3.9 dB
Jacket PVC, black, Ø 5.9 mm f = 10 MHz : 6.9 dB
Power Cable 3x0.85 mm²
Conducto
r
bare copper, 19 x 0.24mm Conductor Resistance 21 ȍ/km
Conductor Cross Section 0.86 mm² (AWG 18) Insulation Resistance > 10 Mȍ x km
Insulation PVC Rated Voltage 300/300 V
Number of Cores 3 Test Voltage 2 kV
Jacket PVC, black, Ø 5.9 mm
HD01P08Z
12mm
