Genelec 6010A Setup Guide

8 9Monitor setup guide
Avoid placing the monitors between 1-2.2 m from the
wall due to wall cancellation.
A monitor should not be placed closer than 1.2 m
from the  oor.
Point the monitors towards your listening position, do
not tilt more than 15 degrees.
Normal listening position height is between 1.2 and
1.4 m.
When you move the speaker closer to the wall, the
cancellation moves higher in frequency range.
You can easily fi nd the cancellation
frequencies with the Genelec AcoustiTape.
Ordercode MAI-0079.
Step 5
Speaker distance
to the front wall
Cancellation
frequency and
wall behind the
speaker
Step 6
Step 7
Monitor heights
(ITU-R BS.775-1
standard)
5 cm
1 m
2,2 m
OK
Avoid
OK
Basics of system setup.
SPL
f
40 200
SPL
f
40 200
‹15°
‹15°
‹15°
1.2-1.4 m
1.2 m

Genelec 6010A Specifications

General

Product color	White
Recommended usage	Other
Suitable for outdoor use	-
Tweeter	Yes
Number of drivers	2
Speaker placement	Tabletop/bookshelf
Audio output channels	1.0 channels
Woofer diameter (imperial)	3 \
Tweeter diameter (imperial)	0.75 \
Impedance	- Ω
Sensitivity	93 dB
Frequency range	73 - 21000 Hz
RMS rated power	24 W
Crossover frequency	3000 Hz
Total Harmonic Distortion (THD)	3 %
Audio RCA inputs	1
Connectivity technology	Wired
AC input voltage	100 - 240 V
Power source type	AC

Weight and Dimensions

Depth	114 mm
Width	121 mm
Height	195 mm
Weight	1400 g
