6 English
SYSTEM SPECIFICATIONS
Lower cut-off frequency, –3 dB: < 73 Hz
Upper cut-off frequency, –3 dB: > 21 kHz
Free field frequency response (± 2.5 dB): 74 Hz–18 kHz
Max. short term sine wave acoustic output
on axis in half space, averaged from
100 Hz to 3 kHz
@ 1 m
@ 0.5 m
> 93 dB SPL
> 99 dB SPL
Maximum long term RMS acoustic output
in same conditions with IEC weighted
noise (limited by driver unit protection
circuit) @ 1 m:
> 91 dB SPL
Maximum peak acoustic output per pair
on top of console, @ 1 m distance with
music material:
> 102 dB
Self generated noise level in free field @
1 m on axis (A-weighted):
< 5 dB
Harmonic distortion at 85 dB SPL @
1 m on axis
Freq: 70…400 Hz
>400 Hz
< 3 %
< 0.5 %
Drivers:
Bass
Treble
76 mm (3”) cone
19 mm (
3
/
4
”)
metal dome
Weight: 1.4 kg (3.1 lb)
Dimensions:
Height including Iso-Pod™ table stand
Height without Iso-Pod™ table stand
Width
Depth
195 mm (7
11
/
16
”)
181 mm (7
1
/
8
”)
121 mm (4
3
/
4
”)
114 mm (4
1
/
2
”)
CROSSOVER SECTION
Input connector: Input: RCA female 10 kOhm: pin +,
sleeve -
Input level for 90 dB SPL output at 1 m: -6 dBu at
volume
control max
Level control range relative to max output: -12 dB
Desktop control operating range: 0 to –4 dB
@ 200 Hz
Crossover frequency, Bass/Treble: 3.0 kHz
Bass Tilt control operating range in –2 dB
steps:
0 to –6 dB
@ 100 Hz
The ‘CAL’ position is with all tone controls set to ‘off’ and the
input sensitivity control to maximum (fully clockwise)
.
AMPLIFIER SECTION
Bass amplifier power with an 8 Ohm load: 12 W
Treble amplifier power with an 8 Ohm load: 12 W
Long term output power is limited by driver
unit protection circuitry
Amplifier system distortion at nominal output
THD+N:
< 0.08 %
Mains voltage: Fixed 100,
120, 220 or
230 V
Voltage operating range: ±10 %
Power consumption
Standby
Idle
Full output
<0.5 W
5 W
35 W
.
