8381A Quick Setup Guide
Needed tools
Inventory
Warnings
E
2 x
B
Torx 20
Do not use blades for opening plastic bags.
Caution! Heavy package. Lift carefully with the help of another person.
70
kg
!
Please only remove the protective foam in front of the drivers after
completely assembling the monitor unit.
2 x
D
5 m
C
0,5 m
A
0,25 m
F
12 x
M4x10
2 x
G
I
Kiitos. Thank you.
L
H
M
8 x
K
WARNING: This loudspeaker may cause traumatic and permanent
hearing damage. Before applying power, read the warnings in the
operating manual and the paragraphs about analogue and digital
input sensitivity.
A CAT45 cable
B Interconnection
cable
C CAT45 cable
D CAT45 cable
E Protective plate
F Bolt
G XLR
H Speakon
I Protective sleeve
J Mains cable
K Rubber feet for
ampliers
L Card
M 8381A Quick Setup
Guide
J
2 x
