Genelec 8381A User Manual

Unpacking and assembling
Remove the two large pieces of foam
padding.
3.
Remove both ampliers and take them out
of their plastic bags.
4.
Remove screws from the box’s base and lift
the box’s top section away.
1.
Remove accessory box, then cut incliner
wedges free and remove them.
2.
70
kg
!
Torx 20
(Optional) If tilting is needed, install incliner
wedge onto lower enclosure. Attach with
4 pcs M4x10 torx bolts.
6.
Remove plastic bag from the lower enclosure
and lift lower enclosure to nal location.
5.
70
kg
!
Torx 20,
max. 1Nm
F x 4

Genelec 8381A Specifications

General

Brand	Genelec
Model	8381A
Category	Speakers
Language	English
