Section 9
Exploded Views
Page 65
ITEM QTY. DESCRIPTION
1 1 TRAY, 530 RV
2 2 NUT FLANGE 5/16-18 LOCK
3 8 NUT HEX 5/16-18 STEEL
4 12 WASHER LOCK M8-5/16
5 13 WASHER FLAT 5/16-M8 ZINC
6 2 SCREW HHC 3/8-24 X 1-1/2 G8
7 1 BELT V-RIBBED 4L X 43.75" LG
8 2 WASHER LOCK M10
9 2 WASHER FLAT 3/8-M10 ZINC
10 1 ALTERNATOR PULLEY
11 4 VIB MNT 1.5X1.38X5/16-18 DR 45
12 1 FAN 7" DIA (NYLON)
13 11 SCREW HHTR #10-32 X 9/16
14 7 WASHER FLAT 1/4-M6 ZINC
15 7 WASHER LOCK M6-1/4
16 7 SCREW HHC M6-1.0 X 12 G8.8
17 1 ENGINE PULLEY
18 1 FAN ENGINE PULLEY RV
19 2 BRACKET MUFFLER SUPPORT
20 2 BOLT CARR 5/16-18 X 1
21 1 EDGE TRIM W/ 3/4" HOLLOW CYL.
22 1 BLOWER HOUSING WALL
23 1 GASKET, LOWER BLOWER HOUSING
ITEM QTY. DESCRIPTION
24 1 FRAME GT530 RV MOUNTING
25 1 SPACER, SAFETY BOLT .375 I.D.
26 2 SCREW HHC 5/16-18 X 3 SPC
27 1.5ft TAPE ELEC UL FOAM 1/8 X 1/2
28 1 DUCT AIR OUT
29 1 GASKET, AIR OUT DUCT
1
GASKET, AIR OUT DUCT OPPOSITE SIDE
30 1 SCREEN, BOTTOM AIR OUT
31 3 WASHER FLAT 1/4-M6 ZINC
32 3 SCREW SWAGE 1/4-20 X 1/2 ZYC
33 5 ISOLATION SPRING
34 1 MUFFLER, 530 RV
35 1 BOLT U 5/16-18 X 1.25 W/SADDLE
36 4 SCREW SHC M8-1.25 X 18 G8.8
37 1 SCREW CRIMPTITE 10-24 X 3/8
38 1 SCREEN SPARK ARRESTOR
39 2 CLAMP EXHAUST
40 1 EXHAUST FLEX
41 1 EXHAUST MANIFOLD
42 6 SCREW CRIMPTITE 10-24 X 1/2
43 6 WASHER FLAT #10 ZINC
44 2 GASKET, EXH BASE, 530 RV
45 2 GASKET, EXHAUST GT530
To Next Page
