Section 9
Exploded Views
Page 67
ITEM QTY. DESCRIPTION
1 1 ENCLOSURE DOOR
2 2 SLIDE LATCH, FLUSH
3 1 FOAM ENCLOSURE DOOR
4 23 NUT FLANGE M6-1.0 NYLOK
* 26 NUT FLANGE M6-1.0 NYLOK (LP)
5 1 BRACKET, ENCLOSURE ELECTRIC HTR
6 1 GROMMET, OIL FILTER
7 1 U CHANNEL 1/8”
8 1 TRAY, 530 RV
9 1 GASKET AIR IN BOTTOM DUCT
10 1 PLUG PLASTIC 1.093-1.125
11 1 GASKET AIR IN TOP DUCT
12 1 DUCT AIR IN ROOF
13 13 SCREW HHTT M6-1.0X12 ZINC
14 1 TOP DIVIDER PANEL
15 1 FOAM, SIDE ENCLOSURE
* 1 FOAM, SIDE ENCLOSURE (LP)
16 1 ENCLOSURE SIDE / BACK
17 1 GROMMET OVAL 31.75X50.8
18 18 SCREW SWT 1/4-20X5/8 W/W
19* 2 SCREW HHC M8-1.25X16 G8.8 (LP)
20* 2 WASHER LOCK M8-5/16 (LP)
21* 2 WASHER FLAT 5/16-M8 ZINC (LP)
ITEM QTY. DESCRIPTION
22* 1 BRACKET, 530 RV REGULATOR (LP)
23 1 FOAM BACK ENCLOSURE ALT SIDE
* 1 FOAM BACK ENCLOSURE ALT SIDE (LP)
24 1 ENCLOSURE ROOF
25 1 ENCLOSURE, BACK PANEL 530 RV
26 1 FOAM BACK PANEL ENCLOSURE
27* 1 REGULATOR ASSY, 530 RV LP (LP)
28 1 UPPER BLOWER HOUSING
29 1 UPPER BLOWER HOUSING GASKET
30 1 EXHAUST DIVIDER PANEL
31 1 MUFFLER HOLD DOWN BRACKET
32 1 ENCLOSURE EXHAUST SIDE PANEL
33 1 FBR GLASS, ENCLOSURE MFLR BACK
34 1 FOAM EXHAUST END ENCL FRONT
35 2 FBR GLASS, ENCLOSURE MFLR SIDE
36 9 SCREW HHTT M6-1.0X8 ZYC
37 1 BUMPER
38 1 STAND OFF
39 1 WASHER, FLAT 1/4”
40 1 WASHER, LOCK 1/4”
41 1 SCREW HHC 1/4-20 X 3/4” G5
42 1 GASKET, SCROLL DUCT
*ITEM FOR MODELS WITH LP
