4
General Information
R-panel Technical Manual
Switch Position
Condition System Low Low Low High Over Over Manual Auto Off
Ready Fuel Bat Oil Temp Speed Crank
Generator Switch is OFF @ X OFF OFF OFF OFF O
in the OFF Mode
System Ready for ON @ X OFF OFF OFF OFF O
Automatic Start
Generator Switch is OFF @ X OFF OFF OFF OFF O
in the MANUAL Mode
Weekly Exerciser X @ Flashing Flashing Flashing Flashing Flashing O O O
is not Set (Note A)
(---------------------------------------1 sec rate -------------------------------------)
Battery Voltage <12.2V X @ ON O O O
for > 1 minute (Non-Latching)
Battery Voltage <6V OFF @ ON O O
For > 0.05 seconds
Unit Shutdown due OFF @ X ON O O
To Low Oil Pressure
Unit Shutdown due OFF @ X ON O O
To High Cooant Temp
Unit Shutdown due OFF @ X ON O O
To Engine Overspeed
Unit Failed to Start OFF @ X ON O O
During it's Crank Cycle
Utility Voltage is Flashing @ X O O
< 60% of Nominal 1 sec rate
Unit Shutdown due OFF @ X Flashing O O
To Low Coolant Level
Engine Speed Signal OFF @ X Flashing O O
Fault/RPM Signal Loss
Control Board is Flashing @ X O O O
In GTS Mode 5 sec ON, 1 sec OFF
@ = Low Fuel Pressure is a Yellow LED and will be ON when fuel pressure is less than 5 inches Water Column
X = indicates that the LED can be ON or OFF depending on the Operating Mode (i.e. Manual, OFF or Auto)
Note A: a RED LED fault indication has priority over the flashing LED's used to indicate exercise time not set
