Generac Power Systems RTS User Manual

19
Section 7 — Exploded Views and Parts List
RTS “HS” Type Transfer Switch
200A Transfer Switch Assembly – Drawing No. 0H1710$-C
ITEM PART NO. QTY. DESCRIPTION
1 0D9618 1 TRANSFER SW. HSB 200A 2P 250V
2 074908 5 SCREW HHTT M5-0.8 X 10 BP
3 0G4478 1 CIRCUIT BREAKER, 200A 2-POLE
4 053640 2 SCREW RHM #8-32 X 3-1/4
5 0F8843 2 BUSBAR, 200A LUG ADAPTER
6 0F8451 2 LUG 300 MCM-6STR
7 0G4413 2 SPACER 200 AMP TRANSFER
8 024334 2 BOLT CARR 1/4-20 X 1"
9 0G6352 2 BUSBAR, 200A TRANSFER SW N1,N2
10 0G6417 1 BUSBAR, NEUTRAL BLOCK
11 0E3375 4 LUG SOLDERLESS 250-#6 AL/CU
12 0F1252 4 SCREW BHSC 1/4-20 X 3/8
13 0E6034 1 STRAIGHT SPADE CONNECTOR
14 0G6320 1 GROUND BAR (5) 2-14 AWG CONN
15 085889 4 NUT HEX 1/4-20 SS
16 0A1661 2 RIVET, POP .156 X .67
17 0E3717A 1 ASSY-NEUT BLK 200-400A W/TAP
18 090388 2 SCREW HHTT M6-1.0 X 12 MM
19 0H10860AL14 1 ENCLOSURE, 200A SE XFER SW
20 0G96490AL14 1 COVER, INSIDE 200A DUAL BREAKER
21 0H10870AL14 1 COVER, TRANSFER SWITCH
22 0H1485 1 CB RISER BRACKET 200A GENERAC
23 0G9650 1 SUBPLATE, 200A SE XFER SW
24 0G3369A REF DECAL TRANSFER SWITCH DATA
0H1713 REF DECAL TRANSFER SWITCH DATA 200
0G5910B REF DECAL TRANSFER SWITCH DATA
25 0E3484 1 DECAL, MANUAL OPERATING
HANDLE
26 0G9651A 1 DECAL, UTILITY SOURCE CONN
27 0G9651B 1 DECAL, GENERATOR/CUSTOMER
CONN
28 0G9651C 1 DECAL, UTILITY DISCONNECT
29 0G8535 1 DECAL, TRANSFER SWITCH INFO
30 0G4220 1 DECAL, NEUTRAL CONNECTION
31 0D3587 1 DECAL, FUSE REPLACEMENT
ITEM PART NO. QTY. DESCRIPTION
32 0C2262 1 DECAL, TERMINAL STRIP
33 0H1480 1 DECAL, TEST SEQUENCE
34 0G3274 1 DECAL LIVE CIRCUIT ENG/FRN/SPN
35 0G3259 1 DECAL, TERMINAL SHOCK HZD BI
36 0G0900 1 DECAL, UL LIST HSB
37 0H0497 1 DECAL FRNT CVR ATS 3R SER DIS
0H0905 1 DECAL FRNT CVR ATS 3R SER DIS
38 026902 3 SCREW HHTT #8-32 X 1/4 CZ
39 058000E 1 NUT TRIC 1/4-20 X .525
40 0A1495 8 SCREW HHTT M4-0.7 X 10 BP
41 064761 4 TIE WRAP UL 5.6 X .10 (NOT
SHOWN)
42 026850 2 WASHER SHAKEPROOF EXT 1/4 STL
43 0E7213 1 THUMB SCREW 1/4-20x1/2
44 0G8411 6 NUT HEX FL WHIZ 1/4-20
45 022097 7 WASHER LOCK M6-1/4
46 0G6429 1 WIRING HARNESS HSB (NOT
SHOWN)
47 0E6193 1 BRACKET, ARM EXTENDER
48 0D6162 2 RIVET POP .156 X .362 AL
49 0E6155 1 ARM EXTENDER PIN
50 0E6303 2 WIRE-A
51 0E6032 2 90 DEGREE UP SPADE CONNECTOR
52 0E6303B 1 WIRE-E1
53 063617 1 RELAY PNL 12VDC DPDT
54 0D2806 1 FUSEBLOCK 30A 600V 2 POLE
55 073590A 2 FUSE 5A X BUSS HLDR73591
56 0H1605 1 BLOCK TERM 20A 5 X 6 X 1100V
57 049897 4 SCREW SHC M8-1.25 X 20 G8
58 022145 2 WASHER FLAT 5/16-M8 ZINC
58 022129 6 WASHER LOCK M8-5/16
59 045771 2 NUT HEX M8-1.25 G8 CLEAR ZINC
60 043107 2 SCREW HHC M8-1.25 X 25 C8.8
61 026902 3 SCREW HHTT #8-32 X 1/4 CZ
62 022473 4 WASHER FLAT 1/4-M6 ZINC
