WALRUS 5000C
Page | 2
PREFACE
aims to answer all questions the user may have
about the product, however, if you have any
doubts or find anything incorrect in this manual,
please contact us directly. Check the heater for
any damage when unpacking and contact the dealer
immediately if any damage is found. If any
troubles arise during application, please
contact General Components or the company who
sold it to you. We shall do our best to provide
service to you.
Thank you for purchasing the
WALRUS 5000C coolant heater. This instruction
book describes the structures, working
principles, installation and operation of the
WALRUS 5000C. For correct use of the heater,
please read this instruction book carefully
before installation and operation. The
instruction book should be saved in a convenient
place for later reference. This instruction book
is subject to revision without notice, but will
conform to the purchased product. This manual
PREFACE ................................. 2
TABLE OF CONTENTS ........................ 2
INTRODUCTION ............................. 3
STRUCTURE ............................... 3
EXPLODED PARTS DIAGRAM ................... 4
DIMENSIONS, mm ........................... 5
ALLOWABLE MOUNTING ANGLE ................. 5
FUEL PUMP ANGLE & SUCTION HEIGHT ......... 8
FUEL LINE CONNECTIONS .................... 9
FUEL STANDPIPE .......................... 10
WIRING DIAGRAM ......................... 13
CONNECTIONS ............................ 14
TIMER CONNECTIONS ...................... 14
OPERATING INSTRUCTIONS.................. 15
CHANGING LANGUAGE .................... 15
PRE-SETTING HEATING TIMES ............. 16
MAINTENANCE .......................... 16
INSPECTION CHECKLIST.................. 16
ADDITIONAL PRECAUTIONS ................ 17
TROUBLESHOOTING ........................ 18
TABLE OF CONTENTS
