PARTS LIST
IMPORTANT: When ordering replacement parts, always give the model number, serial number of the
machine and part number. Also a brief description of each item and quantity desired.
32
PART # DESCRIPTION SPECIFICATIONS QTY
30360-01 DUST CHUTE 1
30360-02 FLANGE BOLT M6X1.0PX12L 13
30360-03 RIGHT SUPPORT SHAFT 1
30360-04 WASHER 6.7X19X2.0T 8
30360-05 FOAM 2
30360-06 CHIP DEFLECTOR 1
30360-07 CAP SCREW M6X1.0PX12L 4
30360-08 REAR TOP COVER 1
30360-09 ROUND HEAD SCREW M6X1.0PX10L 7
30360-10 FRONT TOP COVER 1
30360-11 SHOCK ABSORBER 2
30360-12 PLATE FLAP 2
30360-13 SHAFT 1
30360-14 SET SCREW M6X1.0PX14L 2
30360-15 NUT M6X1.0P 4
30360-15-1 SPONGE PAD 3/8”X1/2”X525L 1
30360-15-2 SPONGE PAD 1
30360-16 CHIP BREAKER 1
30360-17 RETENTION RING ETW-10 2
30360-18 SHAFT 1
30360-19 FIXING PLATE 4
30360-20 SET SCREW M5X0.8PX5L 5
30360-21 FIXING SHAFT 2
30360-22 SPRING 4
30360-23 BUSHING 4
30360-24 OUTFEED ROLLER 1
30360-25 KEY 1
30360-26 SPROCKET 1
30360-27 CHAIN 06BX76P 1
30360-28 CHAIN 06BX52P 1
30360-29 PLATE 4
30360-30 NUT M6X1.0PX16L 5
30360-31 SET SCREW M6X1.0PX16L 4
30360-32 CAP SCREW M8X1.25PX20L 6
30360-33 LOCK WASHER 8.2X15.4 7
30360-34 WASHER 8.5X22X2T 4
30360-35 SCREW 4
30360-36 LEFT SUPPORT SHAFT 1
30360-37 HEX HEAD BOLT M8X1.25PX20L 1
30360-38 WASHER 8X40X4T 1
30360-39 UPPER PULLEY 1
30360-40 WASHER 6.5X23X3T 7
30360-41 RETENTION RING RTW-72 1
30360-42 KNIFE (ITEM #30-364 OU #30-362) 4
30360-43 KNIFE LOCKING BAR 4
30360-43-1 HEX HEAD BOLT M8X1.25PX10 6
30360-44 BEARING 6207-2NSE 1
30360-45 KEY 8X8X40 1
30360-46 SPRING 9
30360-47 HEX HEAD BOLT M5X0.8PX12L 12
30360-48 CUTTERHEAD FOR 30-360 OR #360H FOR 30-360HC 1
30360-49 BEARING 6006-2NSE 1
30360-50 GEAR 1
30360-51 SET SCREW M10X1.5PX12L 4
30360-52 SPACER 2
30360-53 RUBBER PIN 120
30360-54 INFEED ROLLER 20
30360-55 INFEED ROLLER SHAFT 1
30360-56 SPROCKET 1
30360-57 ANTI-KICK BACK SHAFT 2
30360-58 ANTI-KICK BACK PLATE 56
30360-59 SPACER 66
30360-60 FIXING PLATE 1
30360-61 CAP SCREW M8X1.25PX25L 3
30360-62 WASHER 8.5X16X2T 3
30360-63 BEARING HOUSING 1
30360-64 CAP SCREW M8X1.25PX50L 4
30360-64-1 SET SCREW M6X1.0PX6 2
30360-65 GEAR BOX 1
30360-66 OIL SEAL TC28X40X8 1
30360-66-1 RETENTION RING RTW-40 1
30360-67 BEARING 6201Z 5
30360-68 GEAR 1
30360-69 SHAFT 1
30360-70 SHAFT 1
30360-71 GEAR 1
30360-72 GEAR BOX COVER 1
30360-73 OIL SCREW PT1/4”-19T 2
30360-73-1 CAP SCREW M6X1.0PX25 5
30360-74 HOOK 1
30360-75 CAP SCREW M6X1.0PX20L 4
30360-76 SHAFT 1
30360-77 IDLE PULLEY 2
30360-78 BRACKET 2
30360-79 SPROCKET 1
30360-80 PIN 2
30360-81 GEAR ASSEMBLY 1
30360-82 CLUTCH 1
30360-83 OIL SEAL SC25X47X6 1
30360-84 BEARING 6204Z 1
30360-85 SHAFT 1
30360-86 PACKING PIECE 1
30360-87 LEVER 1
30360-88 KNOB 1
30360-89 SHAFT 1
30360-90 BRACKET 1
30360-91 CAP SCREW M10X1.5PX30L 8
30360-92 LOCK WASHER 10.2X18.5 8
30360-93 KEY 5X5X10 2
30360-94 WASHER 10.3X22X2L 8
30360-95 FIXING PIN 4
30360-96 OIL RING P12 1
30360-97 SCREW M20X2.5PX30 2
30360-98 WASHER 60X40X0.05T 4
30360-99 KEY 6X6X40 1
30360-100 BALL _6 1
30360-101 ROUND HEAD SCREW M6X1.0PX10L 24
30360-102 SET SCREW M5X0.8PX5L 2
30360-103 SPROCKET WASHER BW-4 1
30360-104 LOCK WASHER 8.2X15.4 5
30360-105 CAP SCREW M8X1.25PX25L 3
30360-106 WASHER 8.5X16X2T 4
30360-107 LEFT SIDE COVER 1
30360-108 LEFT SIDE SUPPORT COVER 1
30360-109 LEFT SUPPORT 1
30360-110 WASHER 5.3X12X1T 4
30360-111 ROUND HEAD SCREW M5X0.8PX15L 2
30360-112 STOP SWITCH 1
30360-113 ROUND HEAD SCREW M4X0.7PX12L 1
30360-114 START SWITCH 1
30360-115 NUT M5X0.8P 2
