Setting up a dial-in grade / slope
• To create a dial-in grade / slope, press the
automatic grade mode button on the laser or
remote control. The LCD display screen on the
laser and remote control will show the dial-in
function with the X-axis selected.
• To set a grade / slope percentage on the X-axis,
press the grade adjustment buttons on the laser
or remote control to change to the desired number
(positive or negative). When the required grade /
slope percentage has been selected, press the
automatic grade mode button to confirm the
setting and change to the Y-axis.
• To set a grade / slope percentage on the Y-axis,
press the grade adjustment buttons on the laser
or remote control to change to the desired number
(positive or negative). When the required grade /
slope percentage has been selected, press the
automatic grade mode button to confirm the
Y-axis setting. If you do not wish to set a grade on
this axis, press the automatic grade mode button
to complete the dial-in grade / slope operation.
• The instrument will now adjust to your selected
grade(s) / slope(s).
• To change a selected grade / slope, press the
automatic grade mode button to cancel the grade
/ slope operation and press again to begin set up
again.
• To cancel dial-in grade / slope operation and reset
the instrument, press the automatic grade mode
button.
