10
OPERATING FREQUENCY:
GPS: GPS, GLONASS, Galileo a QZSS
Ka narrow: 34.0 GHz, 34.3 GHz, 34.7 GHz, 35.5 GHz (±120 MHz)
Ka wide: 33.4 GHz ~ 36.0 GHz
K narrow: 24.125 GHz (±70 MHz)
K wide: 24.125 GHz (±150 MHz)
MultaRadar: CD/CT
GATSO: RT3/RT4
Laser: 904 nm
TECHNICAL PARAMETERS:
Operation temperature: -20 °C to +85 °C
Storage temperature: -20 °C to +85 °C
Operation voltage: 11 - 26 V DC
Power consumption: 250 mA normal, 330 mA max. (at 12 V)
Dimensions: 101 × 68 × 33 mm
Power Input: Pmax= 3.96 W
Connector polarity: Positive
Power supply fuse: F2A/250V
SAFETY INSTRUCTIONS
We recommend that you install the product using the included bracket with
suction cups on the windshield so that it does not obstruct your view.
Alternatively, the product can be placed in another location provided it is
securely fastened to prevent the device from moving by itself. The location
must have good GPS signal reception. The device must be powered using the
supplied 12V cable (to be plugged into a 12V plug in the vehicle) with a jack
type connector to be connected to the appropriately marked plug on the
device.
Restrictions on placing in service or applicable requirements for
permission to use:
County: BG,CY,DE,DK,EE,ES,FI,FR,GR,IR,ITA,LT,LU,LV,MT,NL,PL,PT,SE,SK
Requirements: Please check your legislation before use.
If you wish to discard electrical and electronic equipment, please contact
your dealer or supplier for further information.
CE - DECLARATION OF CONFORMITY
The manufacturer, GENEVO s.r.o., hereby declares that GENEVO MAX
equipment complies with the essential requirements and other relevant
provisions of Directive 2014/53/EU. The full Declaration of Conformity can
be downloaded here:
www.genevo.com/uploads/ce/DoC.pdf
