GENEVO MAX - Page 3

3
QUICK GUIDE:
Mounting bracket
(horizontal
attachment)
Mounting bracket
(Vertical
attachement)
1. 12V power input
2. 3.5mm jack for
headphones
3. USB-C input for PC
updates
4. Control buttons
5. Status indicator
6. Motion sensor
7. Control buttons
8. Menu button
9. Mounting bracket
10. Laser sensor
1 2 3 4 5 6
7
8
9
10
Powering by the
supplied 12V
power cable.
