Operator's Manual
First Edition • First Printing
Part No. 133136 GRC-12 15
Ground Control Panel
1 7 amp breaker for electric circuits
2 Key switch for platform/off/ground selection
Turn the key switch to the platform position and
the platform controls will operate. Turn the key
switch to the off position and the machine will
be off. Turn the key switch to the base position
and the ground controls will operate.
3 Hour meter
Indicates the number of hours the machine has
been put into use.
4 Platform up/down toggle switch
Move the switch up and the
platform will raise. Move the switch
down and the platform will lower.
5 Red Emergency Stop button
Push in the red Emergency Stop button to the
off position to stop all functions. Pull out the red
Emergency Stop button to the on position to
operate the machine.
Controls
STOP
00009.9
2
3
4
5
1
