User’s Manual—Read before using this equipment
17
ENGLISH
SPECIFICATIONS
Battery Sealed lead-acid battery/rechargeable/12
volt/18 amp-hours
Work Light 5 LEDs
Compressor 260 PSI analog gauge
Inverter — One AC outlet 230 volts AC
Maximum Inverter Output Power 400 watts
Peak Power 800 watts peak surge for a max of 0.3 sec
I2V Accessory Outlet I2 volt, 11 amps max
USB Power Port 5V up to 500 mA
AM/FM Radio self contained speaker. AM 520 to 1710 kHz/FM 88 to 108 MHz
Audio Output Jack 3.5 mm diameter (1/8 inch)
Max Recharging Time (AC) 34 hours
Max Recharging Time (DC) with engine running 12 hours
Jumper Cables and Clamps 6 Gauge/heavy duty clamps/24 inches
