Mechanical Installation
STEP 4 Installing Spindle Motor
What you need:
Insert the spindle motor into the mount holder and secure it with (2) M4×16 screws.
04 Spindle 22
(4) M4×16 Socket
Head Cap Screw
Spindle
(2) M4*16
Socket Head Cap Screw
