Mechanical Installation
STEP 3 Spindle Motor Mount Installation
What you need:
Install the spindle motor mount to Z - Axis Carriage using (4) M4×16 screws.
22
(4) M4×16 Socket
Head Cap Screw
03 Spindle Motor Mount
1
2
(4) M4×16 Socket Head Cap Screw
Spindle Motor Mount
