STEP 10: Install the New Lead Screw
16
5. Align the T-brass nut with the round brass nut.
6. Push the screw to make the T-brass nut through the spring and tightly with the round brass nut.
7. Rotate the lead screw clockwise until the screw rod is exposed to the lead screw holder about 40mm.
Spring
T-brass Nut TabRound Brass Nut RecessLead Screw Holder
40mm
