STEP 10: Install the New Lead Screw
17
8. Push the lead screw into the coupler, and tighten with the lead screw fixing screws after the lead screw
reaches the limit position.
(2) Lead Screw
Fixing Screw
PUSH
New Lead Screw
Coupler
